Support Bracket WK 550/350 HCP
Group: 1826
Part number 162610
This is a replacement for Old Productname (Part number 123456).
Login to see prices and availabilities
Login or registerTechnical Data
H1 | 47 mm |
H2 | 322 mm |
L | 550 mm |
L1 | 102.5 mm |
L2 | 279.5 mm |
L3 | 456.5 mm |
H | 350 mm |
Technical specifications
Permissible stress σ{perm.} | 160,00 N/mm² |
Primary element material | steel |
Surface finish | HCP |
Corrosion protection class | C4 |
Certification
