Support Bracket WK 200/200
Group: 1326
Part number 118170
This is a replacement for Old Productname (Part number 123456).
Login to see prices and availabilities
Login or registerTechnical Data
B | 60 mm |
H | 37 mm |
H1 | 60 mm |
H2 | 28 mm |
H3 | 131 mm |
H4 | 181 mm |
L1 | 31 mm |
L2 | 81 mm |
L3 | 131 mm |
Technical specifications
Permissible stress σ{perm.} | 160,00 N/mm² |
Primary element material | steel |
Surface finish | galvanisch verzinkt (Fe//Zn) |
Corrosion protection class | C2 |
Certification
